Semi-Auto Biochemical Analyzer

Automated Chemistry Analyzer

HF-800A Semi-Auto Biochemical Analyzer

Product Description:
HF-800A is a semi-automatic biochemical analyzer, using imported concave holographic grating as dispersive elements. Adopting grating monochromator invention patent technology, it is specially designed for medium and small-sized hospitals and clinic centers. It covers full range of biochemical test items: Liver, Renal, Lipids, Blood Sugar, Enzymes, Ions, etc. The analyzer is not only highly valued by its good quality and performance, but also favored by its cost-effectiveness.
　

 Features:
★Using imported concave holographic grating as dispersive elements, small wavelength error, high optical performance, precision 16 times higher
★Fully-closed solid-state optical system, grating post-spectro and fixed wavelength, can take dual-wavelength measurement
★20 years of maintenance-free period for grating monochromator, all-digital circuit testing, whole process in one machine
★Full range of biochemical test items: Liver, Renal, Lipids, Blood Sugar, Enzymes, Ions, etc.
Self-check function: self-check system failures after power on

HF-800C Semi-auto Biochemical Analyzer

Product Description:

HF-800C is a semi-automatic biochemical analyzer, developed by our own R&D group, equipped with imported and home-made components.  Ideal for small and medium-sized hospitals and clinic centers to make quantitative biochemical analysis with UV-visible light photometric method, it covers full range of biochemical test items: Liver, Renal, Lipids, Blood Sugar, Enzymes, Ions, etc.  The analyzer is not only highly valued by its good quality and performance, but also favored by its cost-effectiveness.

Features:
★Semi-automatic bench-top biochemical analyzer ★Fully-closed solid-state optical system, test result highly accurate
★Auto-save test result, and print English real-time report and complete report
★Low demand of sample volume
★Power-off protection function
★Real-time clock display(Year, Month, Day, Hour, Minute, Second)
　

PUS-2018 Biochemistry Analyzer(with External Pinter)

Specifications
Wavelength Range : 340nm～700nm
Measurement Range : 0.001～3.000Abs
Precision : ±0.001Abs
Repeatability : ≤0.005Abs
Linearity : ≤±1%
Cross-contamination : ≤1%
Temperature Accuracy : ±0.1℃
Test Temperature : 25℃、30℃、37℃
Test Method : end-point, kinetic, two-point , standard
curve and simple/double wavelength exam.
Colorimetric Pool : Titanium alloy
Reagent : 400μl～800μl Match all kinds of reagent
Sample volume : 20～50μl
Display : Photometric absorbance, density, active
unit, and normal parameters
Packing Details : 680mm×530mm×600mm
N.W.12kgs G.W.15kgs
　

Specifications
Wavelength Range : 340nm～700nm
Measurement Range : 0.001～3.000Abs
Precision : ±0.001Abs
Repeatability : ≤0.005Abs
Linearity : ≤±1%
Cross-contamination : ≤1%
Temperature Accuracy : ±0.1℃
Test Temperature : 25℃、30℃、37℃
Test Method : end-point, kinetic, two-point , standard
curve and simple/double wavelength exam.
Colorimetric Pool : Titanium alloy
Reagent : 400μl～800μl Match all kinds of reagent
Sample volume : 20～50μl
Display : Photometric absorbance, density, active
unit, and normal parameters
Packing Details : 710mm×590mm×460mm
N.W.9kgs G.W.11kgs
　

Specifications
Wavelength Range: 340nm∼750nm
Measurement Range: 0.000∼3.000Abs
Repeatability: ≤0.005
Linearity: ≤1.0%
Cross-contamination: ≤1.0%
Temperature Accuracy: ±0.2℃
Colorimetric Pool: Titanium alloy
Test Method: Absorbency, End-poit, Kinetic,Two-point,
Standard Curve, Control Tube, Factor
Packing Details: 680mm×530mm×600mm
N.W.12kgs G.W.15kgs
Features
1. 7.5" colorful touch screen, can be connected to a mouse,
Windows operating interface.
2. Can store 200~500 test results.
3. Can show real-time reaction curve, and print calibration curve, kinetic
reaction curve, quality-control curve and general report.
4. While not working, the instrument will automatically enter half-voltage
sleep status to save energy.
